Telescopic Arm & Clampshell TA22

TA22
Max. cylinder stroke	mm	550
Max. cylinder pressure	bar	320
Max. cylinder flow	L/min	150
Bucket length(close/open)	mm	1020/1570
Bucket Height(close/open)	mm	2396/2780
Bucket width	mm	1270
Bucket capacity	m³	2.2
Total weight	ton	2.3
Bucket capacity	m³	2.2
Weight	kg	7800
Applicable Excavator	ton	40~55
A Max. vertical digging depth	mm	32300
B Max. vertical digging radius	mm	6850
C Max. vertical digging radius	mm	8800
D Digging depth (reach Max. vertical digging radius)	mm	22370
E Max. working radius	mm	12700
F Max. hoisting height	mm	6600
G Min. turning radius	mm	5758
H Max operating height	mm	14000

products

Appurtenance:

Download catalogue:

Application
Introduction
Features
Recommended Products

Introduction:

This telescopic arm grab is a specialized attachment for excavators, engineered for deep foundation excavation, dredging, and material handling in confined or hard-to-reach areas.

Featuring an extendable boom and a heavy-duty grab bucket, it delivers exceptional reach and lifting capacity, enabling precise soil, sludge, and debris extraction in tasks like trench digging, caisson construction, and underwater operations.

It combine robust structural design with hydraulic precision, making them a reliable choice for heavy civil engineering and construction projects.

Features：

• Quick and convenient city vertical stereo construction tooling is convenient for construction is small and stereo space;

• Easy maintenance, low cost and high yield; Reliable telescopic structure of teel wire rope;

• Design in strict accordance with the safety standard of EU EN791, ensuring the construction safety；

• Clamp can grab soil through excavator equipment with touch type 360°turn.
